The revised crank star with screw caps ensures a clean look. Only for use on frames with 83mm bottom bracket shell width. What matters is the overall balance of the crankset. With regard to the entire crankset, an optimal relationship between the strength of the crank arms, the rigidity of the axle, the bearing position and other features is very important.
When developing the crankset, the overall balance of all individual elements was carefully considered to ensure maximum stability. Outer bearing: With most 68 mm bottom bracket shells, the Hollowtech II with 24 mm axle can be installed so that the bearing sits outside the frame for better weight distribution and greater stability. High-quality precision seals: The Hollowtech II set also has high-quality precision seals in the storage area in order to extend the shelf life and maintain the excellent rotational efficiency in the long term.
The axle and the bearings with a diameter of 24 mm ensure an optimal balance of the crankset and an optimal transmission of the drive force to the bike. The third generation of Saint - the m820 group - was developed under the "Pure Gravity" design philosophy with a clear focus on downhill speed. New Saint is dedicated to DH racing, new Saint enhances concentration and focus through seamless and stable bike control, new Saint accelerates and decelerates at Word cup levels.
Saint HOLLOWTECH II cranks are forged premium Duraluminum to form a light weight, extremely strong crank set. The single-only crank is available with multiple chain ring options. Crank arm length: 170.0 mm. Chain line: 57.9 mm. Chainring mount: 104 mm bolt circle diameter, 4-arm.
Axle diameter: 24 mm (Hollowtech II). Compatible housing width (BSA): 83 mm. Bottom bracket: SM-BB80 Hollowtech II (1.37x24).Compatible with Pressfit bottom brackets. Application: Freeride, Downhill, Enduro, Dirt Jump.
